Product parameters
This 12V-24V DC electric wheel hub motor is perfect for robotics projects due to its high speed and torque. Its factory-produced sealed waterproof structure ensures durability and reliability in all weather conditions. It has a strong, solid construction that makes it ideal for outdoor use.
| Motor performance parameter | |
| Motor model | BL10548HI |
| Operating Voltage(Vdc) | 24~48 |
| Recommended load（Double wheels） | ≤50Kg |
| Direction | CW/CCW |
| Max output current（A） | ≤4.5 |
| Output power（W） | ≤50 |
| Speed(RPM) | 300~600 |
| Rated torque (N.m) | 1.5 |
| Peak torque (N.m) | ≥3.5 |
| Max. Efficiency | 78% |
| Encoder | SPI/AB（1024line）The output |
| Weight (Kg) | ≈1.0 |
