| Attribute | Value |
|---|---|
| Motor Type | BLDC Hub Motor with Permanent Magnets |
| Motor design | Double axle out with 17inch Aluminium rim |
| Rim size | 3.5x17 |
| Matching Tire | 120/70-17 |
| Magnet Height | 50MM |
| No. of Pole Pairs | 16 pairs |
| Rated Power | 8000W |
| Max Power | 11250W (Peak 16000W) |
| Rated Voltage | 72V (72-144V Can be optional) |
| Speed | 115km/h (30-120km/h can be customized) |
| Max No-load RPM | 1160RPM (400-1400rpm customized) |
| Max Torque | 200N.M |
| Max Efficiency | 90% |
| Continious current | 130A |
| Max current | 190A, Peak 260A |
| Brake type | Disc brake |
| Rear Fork width | 200mm |
| Winding Core material | Aluminium |
| Cross Section of Phase wire | 16 mm2 |
| Hall sensor phasing angle | 120 degree |
| Temperature Sensor | Optional |
| Max. Working Temperature | 70 degree, Peak 120 degree |
| Waterproof Grade | IP54 |
| N.W./G.W. | 22kgs/23kgs |
| Package Size | 585840CM |
