Product parameters
Introducing the 14" 72V 40H DC 1800W disc brake hub motor for electric scooter. This motor offers up to 1800W of power, with a 72V voltage and 40H strength. The disc brake design ensures efficient, reliable braking. Enjoy smooth rides with optimal stopping power and long-term reliability.
| Specification | Motor Type: Hub Motor | Brake: Disc Brake |
| Rated Voltage : 72V | Style: two rounds | |
| Magnet Height : 40mm | Stator : iron core | |
| Place of Origin : Jiangsu, China | Color : black/silver | |
| Bearing : double | Certification: CCC, CQC | |
| Waterproof :IP67 | Weight: 13.542kg | |
| Technical Data | Rated voltage | 72v |
| Efficiency | ≥87% | |
| Maximum power | 2500W | |
| Rated power | 1800W | |
| Maximum current | 40A | |
| Continuous current | 29A | |
| Rated Rotation Speed | 700rpm | |
| RPM without load | 750rpm | |
| Speed with load | 70km/h | |
| Maximum torque | 159N.m |
