150-200W 24V 4 inch brushless double shaft wheel hub motor

Home >Products
150-200W 24V 4 inch brushless double shaft wheel hub motor
/skin/lunyee/images/products/banner/150-200w-24v-4-inch-brushless-double-shaft-wheel-hub-motor-2-160.webp

Product parameters

150-200W 24V 4 inch brushless double shaft wheel hub motor

This brushless double shaft wheel hub motor offers 150-200W of power from a 24V system making it suitable for long-term, reliable use. Its 4 inch size is ideal for powering small vehicles and other applications.

size4 inch

Max torque1.3 N.M

Rated voltage24V/36V

Speed 15-18km/h

Description
Get A Quote
More Products
Motor 4 inch brushless gearless motor
Hallsensor yes (5 hall sensor wires)
Brake type V/Disc brake
Motor wheel size(include the tire) 4 inch
Tire the inflate-free tire
Brake mode electric brake
Max torque 1.3 N.M
Rated voltage 24V/36V
Speed  15-18km/h
Rotating speed 350-1600RPM
Tire diameter 100mm
Load weight 50-75kg
No-load current 0.3-1.3A
Weight 1.5kg (with tire)
